Youll be amazed at how easy it is to work the world running only 5 watts! MFJs CW radios are so light and compact you can take them anywhere — trips, vacations, backpacking, even biking!
Heres what you get
Easy Operation: The most user-friendly radio youll ever own. Sets up in seconds — no microprocessor mumbo jumbo.
Great sensitivity: New hotter than ever superhet receiver brings weakest signals in at full volume (Super-quiet FET post amp stage in the IF filter makes this the best CW receiver going).
Excellent Selectivity: Tight CW bandwidth crystal ladder filter fights unwanted QRM and noise to the maximum.
Smooth and Stable VFO: Wide-spaced reduction drive VFO capacitor glides slowly across the easy-to read dial.
True RIT: RIT control has center detent — makes listening or calling off-frequency a snap.
Easy on your ears: Smooth AGC tracks only the signals you want to hear — it never locks onto strong signals outside the audio bandpass. MFJs InstantRecovery AGC snaps the receiver back at full gain after transmitting.
Built in speaker: High efficiency 3″ speaker driven by 100 mW of audio gives great volume.
Rugged Transmitter: Motorola power amplifier transistor delivers full QRP output, tolerates opens and accidental shorts without damage.
SineWave SideTone: Pure 700 Hz CW sidetone makes sending as much fun as receiving!
Semi-QSK: Set adjustable hold transmit/receive switching to suit your normal sending speed or set it for full QSK during contests.
Easy to Power: It uses little power — only 50 mA average on receive and 1.2 amp peak on transmit. Perfect for battery operation in remote locations!
Rugged construction: MFJ CW radios are built on G-10 double-sided plate-through PC boards in our plant. Rugged all-metal cabinet with brushed aluminum front panel and vinyl clad cover.
17 Meter CW transceiver
Download Product Manual
